LED Portal
A 24 × 32 pixel LED art panel: 768 WS2812B LEDs behind a 3D printed pixel grid and frosted acrylic, run by an ESP32-C3 with its own web control page.
Kyle Rodrigues / Maker & Electrical Engineer
Where my curiosity meets design. My designs involve hardware, LED art and unique 3D prints. Join the adventure of my making and the stories behind my projects. - Kyle

A 24 × 32 pixel LED art panel: 768 WS2812B LEDs behind a 3D printed pixel grid and frosted acrylic, run by an ESP32-C3 with its own web control page.

Seven printed infinity-mirror cells form a honeycomb cluster on an upcycled round mirror, with a glowing LED halo.

Individually-addressable RGB LED shoulder patches, built around David Shorey's (ShoreyDesigns) Dragon Scales print-on-fabric technique. Each patch is a sheet of scales printed directly onto mesh, shingled over a printed tray that holds a chain of WS2812B-style ("NeoPixel") LEDs, so every scale (or column of scales) can be lit its own color.

This is a 6 foot diameter hexagonal infinity mirror that contains 3000 WS2811 leds and runs WLED.

Turning Disposable Vape Batteries into WLED Projects

A geodesic globe of 44 ping-pong balls, each lit by its own LED and driven by WLED.
Wearable Addressable LEDs that can be controlled with the WLED app

A custom WLED driver turns an IKEA ÖKENSAND floor lamp into an addressable color lamp.

This is a project to turn 1" PCC pipe and leds into an WLED controlled accent lamp. Head over to my GITHUB for more details.
This was a passion project to create a wearable LEDs that people could sync together at concerts and events

ESP32 powered automated plant managing system

A compact ESP8266 based Neopixel driver with lipo battery charger

An ESP32-S3 WLED driver board the size of two 18650 cells, with fused 5V and 12V LED outputs.
